Modified atmosphere labeling machine

Modified atmosphere labeling machine

Inquiry
  • Overview
  • Description
  • Specifications
Place of Origin China
Minimum Order Quantity 1 set
Packaging Details Composite Wooden Crates
Delivery Time 30 days
Payment Terms To be discussed
辅图 (2)(0aedab7e40).jpg 辅图 (3)(63fd02d8f4).jpg 辅图 (4)(bf724382f4).jpg 辅图 (5)(1adc3bf504).jpg 主图(777c17ec45).jpg



Description:

MAP Labeling Machine is designed for high-precision and stable labeling of various packaging formats. It supports round, flat, and square containers, offering fast changeover and reliable performance. With an intuitive control system and robust construction, it ensures accurate label placement, improved efficiency, and consistent operation for food, beverage, and daily chemical applications.

Specifications:

Model CLS-20 CLS-30 CLS-40 CLS-60
Labeling type Flat labeling Print Labeling Weigh-price labeling Weigh-price labeling
Application Scenario Modified Atmosphere Packaging
Labeling speed 100 packs/min 60 40 60
packs/min packs/min packs/min
Labeling method Contact Air-blow/Piston Air-blow/Piston Air-blow/Piston
Label position Top Top Top Top/Bottom
Print method × Thermal/Thermal transfer Thermal/Thermal transfer Thermal/Thermal transfer
Print speed × 300m/s 300m/s 300m/s
Print resolution × 300 dpi 300 dpi 300 dpi
Label size 20*20mm- 20*20mm- 20*20mm- 20*20mm-
200*140mm 100*140mm 100*100mm 100*100mm
Label roll size 76mm (ID)/300mm (OD) 76mm (ID)/300mm (OD) 76mm (ID)/300mm (OD) 76mm (ID)/300mm (OD)
Weighing accuracy × × ±1g ±1g
Weighing range × × 0-3000kg 0-3000kg
Conveyor height 800mm-900mm 800mm-900mm 800mm-900mm 800mm-900mm
Conveyor direction Right to left Right to left Right to left Right to left
Dimensions(L*W*H) 883*689*1477mm 1285*963*1520mm 1674*963*1520mm 1674*963*1520mm
Power supply 220V/50Hz 220V/50Hz 220V/50Hz 220V/50Hz
Power consumption 580W 920W 1680W 1800kg
Weight 92kg 210kg 296kg 320kg
Operating environment 0°C-40°C
